แผงโซล่าเซลมือ2 ขนาด280วัตต์ สภาพ 99.9% ราคา4500.-จำนวนมาก

รายละเอียดสินค้า

Model STP280-24/Vd
Maximum Power at STC* 285 W
Number of cells 72 (6 x 12)
Dimensions 77.0' x 39.1 ' x 2.0 '
(1956?992?50mm)
Weight 59.5 lb (27 kg)
Open Circuit Voltage (Voc) 44.9 V
Maximum Power Point Voltage (Vmp) 35.4 V
Short Circuit Current (Isc) 8.37 A
Maximum Power Point Current (Imp) 8.06 A
Operating Temperature -40?C to +85?C
Maximum System Voltage 600 VDC
Output Terminal 4.0 mm2 (0.006 inches2), symmetrical lengths (-) 1100 mm (43.3 inches) and (+) 1100 mm (43.3 inches)
Series Fuse Rating 20 A

* STC: Standard Test Conditions - Irradiance 1000 W/m2, Module temperature 25 ?C, AM = 1.5

All technical data at standard test condition
AM=1.5 E=1000W/m Tc=25C
